Vehicle
Scion iQ
A very short four-seat city car, and the packaging is what makes it unusual to work on: the differential sits ahead of the engine, the fuel tank is under the floor, and the steering rack is mounted high — so routine access is nothing like a conventional small car and several jobs require the subframe to drop. Mechanically it is simple, with the 1.3 1NR-FE and a CVT. Its recurring fault is the water pump and the electric power steering column, the latter producing an assist-loss warning that reads through the steering module rather than anything mechanical. Aston Martin sold the same car as the Cygnet, so those parts cross-reference.
Generations
-
First generation 2011–2015
Unconventional packaging with the differential ahead of the engine; electric steering and the water pump are the recurring faults.
- Body styles
- Hatchback
- Platform
- Toyota iQ
- Engines
-
- 1.3 four-cylinder — 1NR-FE · petrol · 69 kW (93 hp) · 118 Nm (87 lb-ft)
- 1.0 — 1KR-FE · petrol · 49–53 kW (66–71 hp) · 91–94 Nm (67–69 lb-ft)
- 1.3 — 1NR-FSE · petrol · 69 kW (93 hp) · 118 Nm (87 lb-ft)
- 1.4 — 1ND-FTV · diesel · 66 kW (89 hp)
- Transmissions
- CVT · 5-speed manual · 6-speed manual · CVT Aisin K41
- Drivetrain
- Front-wheel drive
Information, not instruction
CarGeek is a reference, not a service manual. Its pages are written from public sources and from what other people have found, never from a manufacturer's own service information, so they can be wrong or incomplete for your particular vehicle. Some of what they describe carries real risk: high voltage, fuel under pressure, stored energy, hot and moving parts.
Have anything you intend to act on checked by a trained person against the manufacturer's own procedure for your vehicle. Nothing here replaces that procedure.
