Vehicle

Mitsubishi Pajero

The large ladder-frame four-wheel drive, under three different names depending on market — a fact worth knowing before searching, because the community knowledge is split across all three. Fleet and expedition duty means the population is high-mileage and often heavily loaded, so its diesel's turbo and EGR codes arrive earlier in life than the same engine's would in a car.

WhatsApp Telegram X Email

Mitsubishi Pajero — DY5W-sport · CC BY-SA 3.0 (external)

Generations

First generation (L040/L140) 1982–1991

Largely mechanical injection, so a scan tool reads very little on these — most diagnosis is compression, fuel delivery and the transfer case. **Four-wheel drive is a conventional part-time system and the car has to be stationary to take it up.**
Body styles

SUV

Platform

Mitsubishi Pajero
Engines
2.0 — 4G63 · petrol

2.6 — 4G54 · petrol · 188–220 Nm (139–162 lb-ft)

3.0 V6 — 6G72 · petrol · 105–166 kW (141–223 hp) · 233–304 Nm (172–224 lb-ft)

2.3 — 4D55 · diesel

2.5 turbo diesel — 4D56 · diesel · 62–131 kW (83–176 hp) · 197–400 Nm (145–295 lb-ft)
Transmissions

5-speed manual · 4-speed Aisin automatic

Drivetrain

Part-time four-wheel drive with low range
Second generation (V20/V30/V40) 1991–1999

Super Select four-wheel drive belongs to this generation alone, and it is the reason a fault here is as often the transfer case as the engine. **Mitsubishi built it to 1999**, but CKD assembly carried on far longer — the Philippines to 2008, Colombia and India to 2012 — and those cars are this one. **The Chinese car is not.** Changfeng took the licence in 1999 and sold it as the Liebao Heijingang, Qibing and Q6 until 2021, with engines the Japanese car never had; earlier Beijing and Guangdong joint ventures did badge theirs Mitsubishi, and those carry BAW's own fours.
- V4A5 / V5A51 5-speed automatic
Body styles

SUV

Platform

Mitsubishi Pajero
Engines
2.6 — 4G54 · petrol · 188–220 Nm (139–162 lb-ft)

2.4 — 4G64 · petrol · 82–121 kW (110–162 hp) · 184–221 Nm (136–163 lb-ft)

3.0 V6 — 6G72 · petrol · 105–166 kW (141–223 hp) · 233–304 Nm (172–224 lb-ft)

3.5 V6 — 6G74 · petrol · 139–209 kW (186–280 hp) · 300–333 Nm (221–246 lb-ft)

2.2 — 4RB3 · petrol · China — Beijing Automotive, in the Mitsubishi-badged joint-venture cars

2.4 — BJ492 · petrol · China — Beijing Automotive, in the Mitsubishi-badged joint-venture cars

2.5 turbo diesel — 4D56 · diesel · 62–131 kW (83–176 hp) · 197–400 Nm (145–295 lb-ft)

2.8 turbo diesel — 4M40 · diesel · 92–103 kW (123–138 hp) · 292–314 Nm (215–232 lb-ft)

2.5 turbo — DK4A · diesel · China — Beijing Automotive, in the Mitsubishi-badged joint-venture cars
Transmissions

5-speed manual · 4-speed Aisin automatic · 5-speed V5A51 Mitsubishi automatic

Drivetrain

Super Select four-wheel drive · Part-time four-wheel drive with low range
V60 1999–2006

The 3.2 DI-D diesel arrives; Super Select four-wheel drive.
Body styles

SUV

Platform

Mitsubishi Pajero
Engines
3.0 V6 — 6G72 · petrol · 105–166 kW (141–223 hp) · 233–304 Nm (172–224 lb-ft)

3.5 V6 — 6G74 · petrol · 139–209 kW (186–280 hp) · 300–333 Nm (221–246 lb-ft)

3.8 V6 — 6G75 · petrol · 339–393 Nm (250–290 lb-ft)

2.5 DI-D — 4D56 · diesel · 62–131 kW (83–176 hp) · 197–400 Nm (145–295 lb-ft)

3.2 DI-D — 4M41 · diesel · 118–147 kW (158–197 hp) · 351–450 Nm (259–332 lb-ft)

2.8 turbo — 4M40 · diesel · 92–103 kW (123–138 hp) · 292–314 Nm (215–232 lb-ft)
Transmissions

5-speed manual · 4-speed automatic · 5-speed automatic

Drivetrain

Super Select four-wheel drive
V80 2006–2021

A very long production run — a late example is mechanically a much older design than its registration suggests.
- V4A5 / V5A51 5-speed automatic
Body styles

SUV

Platform

Mitsubishi Pajero
Engines
3.0 V6 6G72 — 6G72 · petrol · 105–166 kW (141–223 hp) · 233–304 Nm (172–224 lb-ft)

3.8 V6 — 6G75 · petrol · 339–393 Nm (250–290 lb-ft)

3.2 DI-D — 4M41 · diesel · 140–147 kW (188–197 hp) · 441 Nm (325 lb-ft)

2.4 — 4G64 · petrol · 82–121 kW (110–162 hp) · 184–221 Nm (136–163 lb-ft) · China

3.0 V6 — 6B31 · petrol · 162–169 kW (217–227 hp) · 276–291 Nm (204–215 lb-ft) · China

3.5 V6 — 6G74 · petrol · 139–209 kW (186–280 hp) · 300–333 Nm (221–246 lb-ft)

2.8 turbo — 4M40 · diesel · 92–103 kW (123–138 hp) · 292–314 Nm (215–232 lb-ft)
Transmissions

5-speed manual · 4-speed automatic · 5-speed automatic V5A51 · 5-speed automatic V5AFW

Drivetrain

Super Select four-wheel drive

Information, not instruction

CarGeek is a reference, not a service manual. Its pages are written from public sources and from what other people have found, never from a manufacturer's own service information, so they can be wrong or incomplete for your particular vehicle. Some of what they describe carries real risk: high voltage, fuel under pressure, stored energy, hot and moving parts.

Have anything you intend to act on checked by a trained person against the manufacturer's own procedure for your vehicle. Nothing here replaces that procedure.
