Vehicle
SsangYong Rodius
The large seven- to eleven-seat MPV, sold as Turismo and Stavic in various markets — all the same vehicle. Unusually for an MPV it is built on a ladder frame with rear-wheel drive and a live axle, sharing much of its running gear with the Rexton, which is where to look for chassis information. The powertrain is the Mercedes-derived XDi diesel and, on many, a Mercedes-design automatic, so those units' data applies. Its recurring faults are the family's turbo-vane sticking and EGR fouling, plus a self-levelling rear suspension on some trims whose compressor and height sensors set their own codes and are easily mistaken for a load or spring problem.
Generations
-
First generation 2004–2013
The Mercedes-derived XDi diesels and a Mercedes-design automatic, so that documentation applies where SsangYong's does not exist.
- Body styles
- MPV · Minibus
- Platform
- SsangYong ladder frame
- Engines
-
- 2.7 XDi — OM612 · diesel
- 3.2 petrol — M104 · petrol
- 2.0 turbo — diesel
- Transmissions
- 5-speed manual · 5-speed automatic · 6-speed manual
- Drivetrain
- Rear-wheel drive · Four-wheel drive
-
Second generation (Turismo) 2013–2019
Renamed Turismo in most markets, on the 2.0 e-XDi with a seven-speed automatic; self-levelling rear suspension sets its own codes.
- Body styles
- MPV · Minibus
- Platform
- SsangYong ladder frame
- Engines
-
- 2.0 e-XDi — diesel · 114 kW (153 hp) · 360 Nm (266 lb-ft)
- 2.2 e-XDi — diesel · 130–131 kW (174–176 hp) · 400 Nm (295 lb-ft)
- Transmissions
- 6-speed manual · 5-speed NAG 5G-Tronic automatic · 7-speed NAG 7G-Tronic automatic
- Drivetrain
- Rear-wheel drive · Four-wheel drive
