Vehicle

Citroën C4

The compact hatchback, and the nameplate where PSA's fuel-borne particulate-filter additive is most often met. Diesel versions carry a separate tank of cerium additive dosed into the fuel to lower soot ignition temperature — so a filter fault here has a second system behind it, with its own level and dosing codes, that no other manufacturer's diagnosis will mention.

Follow
WhatsApp Telegram X Email

Citroën C4
Alexander Migl · CC BY-SA 4.0 (external)

Generations

  • L 2004–2010

    The original; 1.6 HDi at enormous European volume.

    Body styles
    Hatchback · Coupé
    Platform
    PSA PF2
    Engines
    • 1.4 16v — ET3 · petrol · 66 kW (89 hp) · 133 Nm (98 lb-ft)
    • 1.6 16v — petrol
    • 2.0 16v — petrol · 190–202 Nm (140–149 lb-ft)
    • 1.6 HDi — DV6 · diesel · 66–80 kW (89–107 hp) · 215–240 Nm (159–177 lb-ft)
    • 2.0 HDi — DW10 · diesel · 66–103 kW (89–138 hp) · 205–320 Nm (151–236 lb-ft)
    • 1.6 turbo — EP6DT · petrol · 103–110 kW (138–148 hp) · 240 Nm (177 lb-ft)
    Transmissions
    5-speed manual · 6-speed manual · 4-speed automatic · 5/6-speed manual · 6-speed automated manual
    Drivetrain
    Front-wheel drive

  • B7 2010–2018

    e-HDi with stop-start; the reversible alternator complicates supply-voltage diagnosis.

    Body styles
    Hatchback
    Platform
    PSA PF2
    Engines
    • 1.2 PureTech — petrol · 81–96 kW (109–129 hp)
    • 1.4 VTi — EP3 · petrol · 70 kW (94 hp) · 136 Nm (100 lb-ft)
    • 1.6 VTi — petrol · 86–121 kW (115–162 hp)
    • 1.6 THP — petrol · 86–121 kW (115–162 hp)
    • 1.6 HDi — DV6 · diesel · 68–88 kW (91–118 hp) · 230–270 Nm (170–199 lb-ft)
    • 1.6 BlueHDi — DV6 · diesel · 68–88 kW (91–118 hp) · 254–300 Nm (187–221 lb-ft)
    • 2.0 HDi — DW10 · diesel · 110 kW (148 hp) · 340 Nm (251 lb-ft)
    • 1.2 turbo — EB2 · petrol · 81–96 kW (109–129 hp) · 205–230 Nm (151–170 lb-ft)
    Transmissions
    5-speed manual · 6-speed manual · ETG automated manual · 5/6-speed manual · 6-speed automated manual · 6-speed semi automatic · 6-speed Aisin AWTF-80 SC automatic
    Drivetrain
    Front-wheel drive

  • C41 2020–present

    CMP platform, with a fully electric ë-C4 alongside the combustion versions.

    Body styles
    Hatchback
    Platform
    PSA CMP
    Engines
    • 1.2 PureTech — petrol · 74–114 kW (99–153 hp)
    • 1.5 BlueHDi — DV5 · diesel · 75–96 kW (101–129 hp) · 250–300 Nm (184–221 lb-ft)
    • 50 kWh electric — electric · ë-C4
    • 1.2 turbo — EB2ADTD · petrol · 74–114 kW (99–153 hp) · 205–240 Nm (151–177 lb-ft)
    Transmissions
    6-speed manual · Single-speed reduction · 8-speed Aisin UB81E automatic · 6-speed dual clutch · 1-speed direct-drive
    Drivetrain
    Front-wheel drive
