Vehicle

Peugeot 3008

The mid-size SUV, and after the 208 the model this catalogue most obviously lacked. The first car is an MPV rather than an SUV and is worth separating for that reason alone. The second, on EMP2, is where the Hybrid4 arrives: a petrol engine driving the front axle and an electric motor driving the rear, with no mechanical connection between the two ends. That single fact reorganises the diagnosis — a four-wheel-drive fault here is an inverter or a rear motor fault, never a propshaft or a transfer case, because neither exists.

WhatsApp Telegram X Email

Peugeot 3008 — Guillaume Vachey · CC0 (external)

Generations

First generation 2009–2016

An MPV rather than an SUV, on PF2; the diesel Hybrid4 here is the first Peugeot with an electrically driven rear axle.
- Automated manual (AMT) automated-manual
Body styles

MPV

Platform

PSA PF2
Engines
1.6 VTi — EP6 · petrol · 88–121 kW (118–162 hp) · 160 Nm (118 lb-ft)

1.6 THP — petrol · 88–121 kW (118–162 hp) · 240 Nm (177 lb-ft)

1.6 HDi — DV6 · diesel · 80–88 kW (107–118 hp) · 240–300 Nm (177–221 lb-ft)

2.0 HDi — DW10 · diesel · 100–133 kW (134–178 hp) · 340 Nm (251 lb-ft)

2.0 HDi Hybrid4 — DW10 · hybrid · 66–132 kW (89–177 hp) · diesel front axle, electric rear

1.2 turbo — EB2 · petrol · 96 kW (129 hp) · 230 Nm (170 lb-ft)
Transmissions

5-speed manual · 6-speed manual · 6-speed automatic · ETG automated manual · 6-speed automated manual

Drivetrain

Front-wheel drive · Four-wheel drive
P84 2016–2023

EMP2 and a genuine SUV; the Hybrid4 plug-in drives the rear axle electrically with no mechanical link to the engine at all.
Body styles

SUV

Platform

PSA EMP2
Engines
1.2 PureTech — petrol · 96 kW (129 hp) · 230 Nm (170 lb-ft) · wet timing belt

1.6 PureTech — EP6 · petrol · 121–133 kW (162–178 hp) · 240–250 Nm (177–184 lb-ft)

1.5 BlueHDi — DV5 · diesel · 96 kW (129 hp) · 300 Nm (221 lb-ft)

2.0 BlueHDi — DW10 · diesel · 110–133 kW (148–178 hp) · 370–400 Nm (273–295 lb-ft)

1.6 PureTech Hybrid4 — plug-in hybrid · electric rear axle

1.2 turbo — EB2 · petrol · 96 kW (129 hp) · 230 Nm (170 lb-ft)

1.6 — DV6F · diesel · 73–88 kW (98–118 hp) · 300 Nm (221 lb-ft)
Transmissions

6-speed manual · 5-speed manual · 6-speed Aisin EAT-6 automatic · 8-speed Aisin EAT-8 automatic

Drivetrain

Front-wheel drive · Four-wheel drive

Service information

Peugeot Service Box (external) — Workshop literature

Information, not instruction

CarGeek is a reference, not a service manual. Its pages are written from public sources and from what other people have found, never from a manufacturer's own service information, so they can be wrong or incomplete for your particular vehicle. Some of what they describe carries real risk: high voltage, fuel under pressure, stored energy, hot and moving parts.

Have anything you intend to act on checked by a trained person against the manufacturer's own procedure for your vehicle. Nothing here replaces that procedure.
